Products




Penn Hills Scientific



Reagents, Solvents and Standards for Karl Fischer Titration



Penn Hills Scientific is proud to offer Karl Fischer reagents, solvents, standards, solutions and other supplies for Karl Fischer titrators. Please use the below menu to browse reagent information by instrument or view the full list of reagents offered by Hydranal®. If you have any questions about any of our products or are unsure of which reagent is best suited to your needs, call us at 412-841-6988 for assistance.


Get your order started today by calling 412-841-6988 or by emailing us at !






Karl Fischer Reagent Information by Instrument:



Aquapal and Aquamax | Aquatest 2010 | Return to Products



Karl Fischer Reagents and Standards for Aquamax and Aquapal


ITEMProduct #PRICE($)
Cou-Lo Formula Reagent Pack, 8 x 100ml anode (vessel) reagent, 8 x 5 ml cathode (generator) reagent. Specially formatted for oil samples. 61000 220.00
KF WATER STANDARD, 0.10 mg/g (100 PPM) For checking calibration of coulometric KF equipment. Ten 5 ml ampoules089984275.00
KF WATER STANDARD, 1.0 mg/g (0.1 %) For checking calibration of coulometric KF equipment. Ten 5 ml ampoules089986275.00
Hydranal Coulomat A, Vessel Solution, 500 ml3480775.00
Hydranal Coulomat AG-H, Vessel Solution, 500 ml3484385.00
Hydranal Coulomat CG, Generator Solution, 10 X 5 ml ampoules 34840-0165.00
Hydranal Coulomat CG, Generator Solution, 25 ml34840-0244.00

Back to top of page





Karl Fischer Reagents and Standards for all Aquatest Models


ITEMProduct #PRICE($)
Pyridine-Free Vessel Solution Kit: Consists of four 200ml bottles 90000 155.00
Pyridine-Free Vessel Solution Kit: 500ml bottle 99926 70.00
Pyridine-Free Vessel Solution Kit: Consists of six 500ml bottles 99927 350.00
2% Water Standard: 40ml bottle 92382 40.00
Pyridine-Free Generator Solution: Consists of ten 5ML Ampoules 99782 60.00
Pyridine-Free Generator Solution: 125 ML Bottle 99781 60.0
0.1% Water Standard: Consists of ten 5ML Ampoules 99733 70.00
1.0% Water Standard: Consists of ten 5ML Ampoules 99881 70.00


Back to top of page





Hydranal® Reagents for Karl Fischer Titrators:



One Component Volumetric Reagents | Two Component Volumetric Reagents Coulometric Reagents | Hydranal Standards | Return to Products



Hydranal® Reagents from Riedel de Haen are patented formulations of Karl Fischer reagents for water determination by either volumetric or coulometric procedures. Hydranal® reagents deliver accurate results with rapid titration and stable end points. Most of these reagents are also free of halogenated hydrocarbons and 2-methoxyethanol. Use this guide to choose the Hydranal® reagents for your application.


One Component Volumetric Reagents:


Hydranal Composites contain all the reactants (Iodine, sulphur dioxide and imidazole) dissolved in diethyleneglycolmonomethyl ether (degee). The loss of titre is less than 10% per year. Volumetric reagents have a two-year minimum shelf life for an unopened bottle.


Anolytes
ITEMPNPRICE
HYDRANAL® COMPOSITE 1
One component reagent
1 ml = approx.0.7-1.0 mg H20		 34827

1L - 77.77

6 x 1L - 405.79
HYDRANAL® COMPOSITE 2
One-component reagent.
1 ml= approx. 2 mg H2O.		 34806 1L - 77.77
2.5L - 168.30
6 x 1L - 394.20
4 x 2.5L - 585.53
HYDRANAL® COMPOSITE 5
General one-component reagent.
1ml= approx. 5 mg H2O		 34805 1L - 77.77
2.5L - 168.30
6 x 1L - 405.79
4 x 2.5L - 585.35


Working Medium Solvents to be used with Hydranal Composites
ITEMPNPRICE
HYDRANAL® LIPOSOLVER CM
For water determination in non-polar substances like fats & oils.
Contains chloroform and methanol.		 37855

1L - 56.32

6 x 1L - 294.03
HYDRANAL® LIPOSOLVER MH
For water determinations in non-polar substances likes fats & oils.
Contains methanol and hexane.		 37826 1L - 56.32
2.5L - 294.03
HYDRANAL® METHANOL DRY
A custom made solvent for titration with a maximum water content of 100 ppm-0.01%		 34741 1L - 22.22
2.5L - 41.25
6 x 1L - 116.05
4 x 2.5L - 143.66
HYDRANAL® Solver (Crude Oil)
Working medium containing xylene and chloroform for water determination of oils.		 34741 1L - 75.02
2.5L - 165.44
6 x 1L - 391.49
4 x 2.5L - 574.53


Specialty Reagents for Aldehydes & Keytones
ITEMPNPRICE
HYDRANAL® COMPOSITE 5K
Titrant for water determination in ketones and aldehydes
(1 ml= approx. 5 mg H2O)		 34816

1L - 56.32

6 x 1L - 294.03
HYDRANAL® LIPOSOLVER MH
For water determinations in non-polar substances likes fats & oils.
Contains methanol and hexane.		 37826 500 mL - 66.22
1L - 107.69
6 x 500mL - 345.51
6 1L - 561.88
HYDRANAL® KETO SOLVER
Solvent component for water determination in aldehydes & ketones.
Suppresses side reactions that generate water or consume titrant.
Contains no halogenated compounds.		 34738 1L - 76.12
6 x 1L - 369.99
HYDRANAL® WORKING MEDIUM
Solvent system which contains chloroethanol and chloroform.
For the determination of water in aldehydes and ketones.		 34817 1L - 79.53
6 x 1L - 427.13
HYDRANAL® MEDIUM K
Working Media used for volumetric KF titration in ketones & aldehydes
To be used with Hydranal Composite 5K.		 34698 1L - 83.27
6 x 1L - 413.27
HYDRANAL® COMPOSOLVER
An ethanol-based working medium formulated for use with the standard one-component Hydranal® Composites.
It permits a methanol-free analysis using a single component reagent.		 34734 1L - 46.75
2.5L - 96.47
6 x 1L - 243.76
4 x 2.5L - 335.61

Back to top of page





Two Component Volumetric Reagents:


Hydranal With two component reagents, the reactants are in separate bottles. The titrant is a solution of iodine and alcohol. The solvent solution contains the sulphur dioxide and imidazole in a specific alcohol. The reagents remain stable and unchanged for a minimum of two years as long as the bottles remain unopened.


Titrants
ITEMPNPRICE
HYDRANAL® TITRANT 2
One component reagent
One ml is equivalent to 2 ml + 0.01 mg H20		 34811 1L - 59.84
2.5L - 129.80
6 x 1L - 312.40
4 x 2.5L - 451.55
HYDRANAL® TITRANT 5
One ml is equivalent to 5.00 + 0.02 mg H20		 34801 1L - 64.57
2.5L - 129.80
6 x 1L - 336.71 4 x 2.5L - 451.55


Solvents
ITEMPNPRICE
HYDRANAL® Solvent S
A methanol based standard solvent for volumetric KF applications.		 34800 1L - 59.29
2.5L - 122.65
6 x 1L - 309.10
4 x 2.5L - 426.25
HYDRANAL® SOLVENT CM
Solvent component containing methanol and chloroform for the determination of non-polar samples like oils and fats.		 34812 1L - 67.43
2.5L - 148.50
6 x 1L - 391.49
4 x 2.5L - 16.56
HYDRANAL® SOLVENT OIL
For water determination in non-polar substances like fats & oils.		 34749 1L - 75.02
6 x 1L - 391.49


Specialty Reagents for Aldehydes & Keytones
ITEMPNPRICE
HYDRANAL® SOLVENT E
An ethanol based working medium containing imidazole, sulphur dioxide and diethanolamine.
Can be used in the analysis of aldehydes & ketones when used with other methanol-free reagents.		 34730 1L - 58.74
2.5L - 121.33
6 x 1L - 306.46
4 x 2.5L - 421.96
HYDRANAL® TITRANT 2E
A two component reagent based on ethanol. Can be used with any combination of traditional solvents. When used with Hydranal Solvent E, it provides a methanol-free system for the analysis with a titre of 2.		 34723 1L - 59.84
6 x 1L - 312.40
HYDRANAL® TITRANT 5E
A two-component reagent based on ethanol. Can be used with any combination of traditional reagents. When used with the Hydranal Solvent E, it provides a methanol-free system for the analysis with a titre of 5.		 34732 1L - 59.84
2.5L - 129.80
6 x 1L - 312.40
4 x 2.5L - 451.55

Back to top of page





Coulometric Reagents:


Coulometry usually requires the use of an anolyte and a catholyte. Hydranal® anolytes contain iodide and a sulphur dioxide/imidazole buffer in a suitable solvent. Coulometric reagents have a shelf life of 5 years, as long as bottle remains unopened.


Anolytes & Catholytes
ITEMPNPRICE
HYDRANAL® COULOMAT A
Anolyte standard two component coulometry.
Contains methanol and chloroform as the solvents.
Water capacity is > 10 mg/ ml.		 34807

500mL - 76.67

6 x 500mL - 399.85
HHYDRANAL® COULOMAT AG
For coulometry in cells with or without diaphragm. Free of carbon tetrachloride and chloroform.		 34836 500mL - 76.23
6 x 500mL - 397.54
1L - 124.74
6 x 1L - 695.53
HYDRANAL® COULOMAT AG-H
Coulometric analysis for cells with or without a diaphragm.
Effective for very polar samples(long-chained hydrocarbons).
Free of carbon tetrachloride and chloroform.		 34805 500mL - 85.69
6 x 500mL - 463.76
HYDRANAL® COULOMAT AD
For coulometry in cells without a diaphragm. Free of carbon tetrachloride and chloroform.		 34810 500mL - 99.55
6 x 500mL - 519.42
HYDRANAL® COULOMAT CG
Standard catholyte for coulometric cells with a diaphragm. It contains protected ammonium salts as the reactive component and methanol. 25 ml is packaged in a septa-top vial and 50 ml in 10x5ml ampules.		 34810 25mL - 35.64
50mL - 61.49
6 x 25mL - 185.90
6 x 50mL - 321.20


Specialty Reagents for Aldehydes & Ketones
ITEMPNPRICE
HYDRANAL® COULOMAT AK
Anolyte for coulometric water determination in samples containing ketones.		 34820

500mL - 176.77

6 x 500mL - 922.68
HYDRANAL® COULOMAT CG-K
Catholyte for coulometric water determination in samples of aldehydes & ketones. Packaged as 10x5ml ampules.		 34821 50mL - 156.42
6 x 50mL - 816.31
HYDRANAL® COULOMAT OIL
New anolyte for determination of oils. Based on methanol, with addition of aromatic and halogenated hydrocarbons to aid solubility.		 34868 100mL - 24.31
500mL - 82.39
6 x 100mL - 126.72
6 x 500mL - 429.99


Specialty Reagents
ITEMPNPRICE
HYDRANAL® COULOMAT E
Replaces much of the methanol with ethanol reducing the toxicity without affecting performance. Can be used in systems with or without a diaphragm.		 34726

500mL - 89.21

6 x 500mL - 465.63
HYDRANAL® COULOMAT AF7
Anolyte for two-component coulometry, specifically for the AF7 coulometer. It is used with Composite 5 as the catholyte.		 34829 1L - 162.03
6 x 1L - 845.79


Buffers
ITEMPNPRICE
HYDRANAL® BUFFER
For KF titrations of samples containing strong acids. Buffer capacity: 5 mmoles acid per ml.		 34804

500mL - 39.49

6 x 500mL - 205.92
HYDRANAL® BUFFER BASE
For KF titrations of samples containing strong bases. Contains salicylic acid.
Buffer capacity: 1 mmoles base/ ml.		 37859 500mL - 39.49
6 x 500mL - 205.92
1L - 67.10
6 x 1L - 350.24


Back to top of page




Hydranal® Standards:


Standards are necessary to standardize and control reagents, to check reliability of the titrator and to test instruments according to the requirements of ISO9000, GMP, GLP and FDA guidelines.


Certified Standards
ITEMPNPRICE
HYDRANAL® WATER STANDARD 0.10
A certified standard containing 0.01 mg of H2O per g(1 g = 1.16 ml). A Manufacturer’s Test Certificate with exact specifications is included. 40 ml is packaged as 10x4ml ampules.		 34847

40mL - 71.39

6 x 40mL - 372.68
HYDRANAL® WATER STANDARD 1.0
A certified standard containing 1.00 mg of H2O per g(1 g = 1.0 ml). A Manufacturer’s Test Certificate with exact specifications is included. 40 ml is packaged as 10x4ml ampules.		 34828 40mL - 71.39
6 x 40mL - 372.68
HYDRANAL® WATER STANDARD 10.0
A certified standard containing 10.0 mg of H2O per g(1 g = 1.0 ml). A Manufacturer’s Test Certificate with exact specifications is included. 80 ml is packaged as 10x8 ml ampules.		 34849 80mL - 71.39
6 x 80mL - 372.68
HYDRANAL® WATER STANDARD OIL
Low ppm standard for coulometric KF Titrations.
Exact value stated on C/ A		 34694 80mL - 98.98


Other Standards
ITEMPNPRICE
HYDRANAL® WATER STANDARD KF OVEN
Specially designed to check/control/ validate KF ovens. Consists of finely milled potassium citrate-1-hydrate with a theoretical water content of 5.55% by weight.		 34748

10gm - 46.31

6 x 10gm - 241.34
HYDRANAL® COULOMAT AG OVEN
Anolyte for coulometric water determinations using a KF Oven.
Ensures low error even for long duration determinations. Free of halogenated hydrocarbons.		 34739 500mL - 89.43
6 x 500mL - 466.73
HYDRANAL® STANDARD 5.00 NON-HYGROSCOPIC
A non-hygroscopic butanol/xylene mixture for volumetric standardization. Water content is 5.00 +0.02 mg per ml.		 34813 100mL - 17.71
6 x 100mL - 92.40
500mL - 40.48
6 x 500mL - 211.20
HYDRANAL® WATER-IN-METHANOL STANDARD 5.00
A standard design specifically for use in doing back titrations. Water content is 5.00 + 0.02 mg per ml.		 34802 1L - 38.72
50mL - 28.27


Hydranal® Grade Solvents for Karl Fischer Titrations
ITEMPNPRICE
HYDRANAL® BENZOIC ACID
 37862

500gm - 38.83

6 x 500gm - 202.40
HYDRANAL® IMIDAZOLE 37864 500gm - 66.66
6 x 500gm - 347.93
HYDRANAL® SALICYLIC ACID 37865 500gm - 29.48
HYDRANAL® CHLOROFORM 37863 1L - 42.13
6 x 1L - 219.56
HYDRANAL® XYLENE 37866 1L - 51.37
6 x 1L - 267.96


Desiccants
ITEMPNPRICE
HYDRANAL® HUMIDITY ABSORBER
 34788

500gm - 34.54

6 x 500gm - 179.85
KARL FISHER DRI ALERT 85001 500gm - 34.54
6 x 500gm - 179.85

Back to top of page
